功用与详细介绍/Brief Introduction：

机械适于特色三通管装灌阀，适于于水剂和膏霜类厂品的装灌，尤为对高凝固点介质（如浓酱、朝天椒酱、番茄酱、种衣剂、微乳剂、自功隐藏剂等）的郊果会比较清晰，且计算精度较高。机械适于PLC可和程序编写把握，并配6屏幕尺寸触感屏组排页面机系统，进行 自功进瓶，自功装灌，自功出瓶，的的设备，气动系统元零件均适于全国厂家，抓实了非常出色的质和坚持下去稳定性的效能。本的的设备构成简便，操作使用便捷，是在国内满意的造成高凝固点介质的装灌的的设备。机械增配了控制渗漏与金属拉丝机的装灌闷头，抓实装灌之后后无渗漏，无金属拉丝机。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

特征/Characteristic：

◆调整体统——用三凌PLC调整体统，包装用药量随机的调准。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆运营表层——6英尺彩屏手触式运营表层，直观教学比较简单、安全防护可以信赖Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆工作不断改进——切料有防漏滴设备，可不同原料特质满足下潜包装工作。（此工作能够挑选）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆机械电子器件——均选择国家知名品店牌牌子，为了确保主设备的应急可信、更准确高朝；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆机械装备核心安全装置——机械设备核心安全装置均主要使用高品质304不锈铝制作方法,见谅须要接处货品能能主要使用316L另记费用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆数值检验——雷达回波图数值，对工作任务产品的生产数量抽象概念表现形式。Counting test, real-time, intuitive reflect the yield of work.◆装罐监测——无瓶不灌、瓶数没有不灌Bottle filling test - no bottle no filling, not enough◆系统运营维护情形——远程服务器完全符合GMP想要，可解乏拆装工作、的清洗系统运营维护。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆替换技术参数——换灌装设备技术参数时，只需要方便调准，枯燥办成。Changing specifications - change the filling specifications, simply adjust, easy fix.◆安全运行低能耗——运行低能耗了安全架构图，使机设备的控制低能耗愈发干净的健康。（此安全运行低能耗可不可以配置）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

技术水平参数表/technical parameters：

包装头数The number of filling head	8头💧（能选4、6、8、🍬10、12灌装生产线头）8 head (optional 4, 6, 8, 10, 12 filling head)
采用瓶径 Applicable bottles Drive	Ф33-Ф100 mm
计量校准高精度measure precision	±1%
罐装数量Canned capacity	150-1000ml
生产方式效率Production Capacity	2400-4000瓶/小时候2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
